Description
Camera
Image Sensor2 MP CMOS
Max. Resolution1920 (H) × 1080 (V)
Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter TimePAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
Day & NightColor
Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360°
Signal SystemPAL/NTSC
Lens
Lens Type3.6 mm, 6 mm fixed lens
Focal Length & FOV3.6 mm, horizontal FOV: 83.0°, vertical FOV: 44.4°, diagonal FOV: 98.0°
6 mm, horizontal FOV: 51.0°, vertical FOV: 28.5°, diagonal FOV: 58.7°
Lens MountM16
Illuminator
Supplement Light RangeUp to 40 m
Image Parameters SwitchSTD/HIGH-SAT
Image SettingsBrightness, Sharpness, Mirror, Smart Light, Defective Pixel Correction
Frame RateTVI: 1080p@30fps, 1080p@25fps
AHD: 1080p@30fps, 1080p@30fps
CVI: 1080p@30fps, 1080p@25fps
CVBS: PAL/NTSC
Wide Dynamic Range (WDR)≥130 dB
Image EnhancementBLC, HLC
White BalanceATW/MANUAL
White LightAUTO/OFF
AGCSupport
Interface
Video OutputSwitchable TVI/AHD/CVI/CVBS
General
MaterialFront Cover: Metal
Main Body: Plastic
Dimension77.1 mm × 82.6 mm × 208.9 mm (3.04″ × 3.25″ × 8.22″)
Approx. 441 g ( 0.97 lb.)
Operating Condition-40° C to 60° C (-40° F to 140° F), Humidity 90% or less (no condensation)
CommunicationHIKVISION-C
LanguageEnglish
Power Supply12 VDC ± 25%
*You are recommended to use one power adapter to supply the power for one camera.
ConsumptionMax. 8.5 W
Approval
ProtectionIP67
